기타 시험기

Model

HT-1200

HT-1600

측정 온도

Up to 1200℃

Up to 1600℃

주파수 범위

20Hz~ 150kHZ

최대 샘플링 비율

1MHz

정확도

0.005%

분해능

1/1,000,000 (1ppm)

소프트웨어

No need PC (USB/Lan cable를 통한 데이터 수집 )

표준 액세서리

진동탐지기, 음향탐지기, 자극 인가장치, 서포트, 표준시험바, 케이스

옵션

3D waterfall plot S/W, 품질관리 S/W 패키지, 자동측정 스테이션

추가 챔버

산화 방지 불활성 가스 흐름시스템

전원

240Vac (50~60Hz)

표준 액세서리

Vibration detector

For measurement of vibrations up to 150kHz

Acoustic vibration detector

For measurement of vibrations up to 100 kHz

Set of excitation devices

A complete set of hammers for different kind of materials under test

Set of nodal supports

for supporting bars, tubes and disks in specific modes of interest

Reference test bar with test certificate

A very stable ceramic reference object used as reference and

verification object

PC mouse, Flight Case and Instruction manual

A ruggedized flight case to safely pack and protect all the system

components when traveling or just to store

All connecting cables
